Main Function:

Leads Recording: I,II,III avF,avL, V1,V2,V3,V4,V5,V6, each lead can record the heart rate (one by one) heart rate synchronously and perfectly.

Waveform Display: 3/6 Channel switch display synchronously.

Background Shows: Help to assess the ECG Parameters, immediately grasp the overview of cardiac function.

Gain Adjustment: 1/2 , 1 and 2mV optional, according to the actual situation to display a complete ECG.

Waveform Scrolling Speed: Three kinds of Analysis Modes: Slow, Normal and Fast, more conductive to analyze the ST segment, P-wave and QT and other data.

Shortcut Key: Waveform freeze button, LCD display wake up Button, Abnormal Event Button.

List Of Accessories:

• Batteries and Chargers
• Lead Cable
• Data Cable
• Lead Adapter Cable
• Strap and Retaining Sleeves

Technical Parameters:

• Sampling Rate -128Hz for Per Channel
• A/D Conversion – 16 Bit
• Analog Bandwidth – 0.5Hz- 25HZ
• Recording- Full Disdosure, No Data Compression
• Data Mode- DMS, BMS
• Gain Setting – 1/2, 5 mm/mV, Tolerance of +/- 6
• 1, 10 mm/mV, Tolerance of +/- 6
• 2, 20 mm/mV, Tolerance of +/- 6%
• Recording Channels – 3/12
• LCD Display – 50mm X 36mm
• Languages – English
• Storage Media – TF Card , 2G or more
• Operating Duration – 24-48 Hour Interface – USB
• Weight – 55gDimension – 84mm X 70mm X 20mm
